When MySQL is Slow: Replacing MySQL with PrestoDB 0.246

By Stephen Krings

Former Security Operations Engineer at Cloudflare, Inc.

github.com/kringz

twitter.com/stephenkrings
email: stephen <at> gigashock *dot* com

Intro

I found it fairly straightforward to move data from MySQL to PrestoDB. PrestoDB is excellent for read-only queries with large datasets. PrestoDB differs from Starburst Presto. If you're using Starburst Presto, see this post.

Why in the world do I need PrestoDB?

The truth is: I probably don’t need to use a query engine this powerful. PrestoDB is for clients that have terabytes of data with billions of rows distributed across hundreds of servers.

This project is quite small in comparison; the database I'm using is only ~11 gigabytes with ~18 million rows and is stored on one server.

The dateset is, however, large enough to make my out-of-the-box MySQL database choke under the pressure of a "LIKE '%value%'" query. Running these queries in MySQL takes about 3x longer compared to PrestoDB and fully consumes the capacity of my server's hardware in the meantime.

PrestoDB quickly handles the same "LIKE '%value%'" query out-of-the-box and with ease, on the same hardware I am using with MySQL.

Tutorial

This tutorial will provide instructions for installing and

configuring the following software on Ubuntu 20.04.01. Recommended:

PrestoDB 0.246
Minio Python3 s3cmd-2.0.1 openjdk-11-jre-headless

Optional: vim screen

This tutorial assumes the existence of a MySQL database on the same system.

$ sudo apt update

Install Python3:

$ sudo apt install python3

$ sudo apt-get install python-dateutil

$ sudo ln -s /usr/bin/python3 /usr/bin/python

I'm using vim as a text editor:

$ sudo apt-get install vim

Install screen to make things easier:

$ sudo apt-get install screen

Install Java:

$ sudo apt install openjdk-11-jre-headless

$ mkdir ~/Desktop/source

$ cd ~/Desktop/source

Download and Install Minio

$ wget https://dl.min.io/server/minio/release/linux-amd64/archive/minio_0.0.20210116021944_amd64.deb

$ sudo dpkg -i minio_0.0.20210116021944_amd64.deb

$ sudo mkdir /mnt/data

$ sudo chown -R user /mnt/data && sudo chmod u+rxw /mnt/data

Note: 'user' is my username in Linux.

Edit ~/.bashrc

$ vim ~/.bashrc

Add the following lines:

MINIO_ROOT_USER=minioadmin
MINIO_ROOT_PASSWORD=minioadmin

$ source ~/.bashrc

Run Screen

$ screen

Press ENTER

Run Minio

$ minio server /mnt/data

Detach your screen (ctrl + a + d)

Download and Configure s3cmd:

$ wget https://sourceforge.net/projects/s3tools/files/s3cmd/2.0.1/s3cmd-2.0.1.tar.gz

$ tar xzf s3cmd-2.0.1.tar.gz

$ touch ~/.s3cfg

$ vim ~/.s3cfg

# Setup endpoint
host_base = localhost:9000
host_bucket = localhost:9000
bucket_location = us-east-1
use_https = False
# access keys
access_key = minioadmin
secret_key = minioadmin
# enable s3 signature apis
signature_v2 = False

$ cd s3cmd-2.0.1

Create your bucket:

$ ./s3cmd mb s3://data

View your buckets:

$ ./s3cmd ls s3://

$ cd ~/Desktop/source/

Download the PrestoDB Server:

$ wget https://repo1.maven.org/maven2/com/facebook/presto/presto-server/0.246/presto-server-0.246.tar.gz

Download the PrestoDB CLI:

$ wget https://repo1.maven.org/maven2/com/facebook/presto/presto-cli/0.246/presto-cli-0.246-executable.jar

$ sudo chmod +x presto-cli-0.246-executable.jar

Unpack Presto:

$ tar xzf presto-server-0.246.tar.gz

Changing the filename here to simplify things:

$ mv presto-server-0.246 presto

$ cd presto

$ mkdir etc

$ cd etc

$ mkdir catalog

Create config.properties:

$ touch config.properties

$ vim config.properties

coordinator=true
node-scheduler.include-coordinator=true
http-server.http.port=8080
query.max-memory=3GB
query.max-memory-per-node=1GB
discovery-server.enabled=true
discovery.uri=http://localhost:8080

Create jvm.config:

$ touch jvm.config

$ vim jvm.config

-server
-Xmx5G
-XX:+UseG1GC
-XX:+UseGCOverheadLimit
-XX:+ExplicitGCInvokesConcurrent
-XX:+HeapDumpOnOutOfMemoryError
-XX:OnOutOfMemoryError=kill -9 %p
-Djdk.attach.allowAttachSelf=true

Create node.properties:

$ touch node.properties

$ vim node.properties

node.environment=production
node.id=ffffffff-ffff-ffff-ffff-ffffffffffff
node.data-dir=/mnt/data

Create minio.properties:

$ cd catalog

$ touch minio.properties

$ vim minio.properties

connector.name=hive-hadoop2
hive.metastore=file
hive.metastore.catalog.dir=s3://data/
hive.s3.aws-access-key=minioadmin
hive.s3.aws-secret-key=minioadmin
hive.s3.endpoint=http://localhost:9000
hive.s3.path-style-access=true
hive.s3.ssl.enabled=false
hive.allow-drop-table=true

Create your MySQL config for Presto:
Use your MySQL credentials here.

$ touch mysql.properties

$ vim mysql.properties

connector.name=mysql
connection-url=jdbc:mysql://127.0.0.1/?useSSL=false&allowPublicKeyRetrieval=true
connection-user=stephen
connection-password=pa55w0rd!awaeqewqeqweqwAAA

Open another screen:

$ screen

$ ~/Desktop/source/presto/bin/launcher run

Wait until you see ==== SERVER STARTED ====

Detach your screen (ctrl + a + d)

$ cd ~/Desktop/source

Run the presto CLI:

$ ./presto-cli-0.246-executable.jar

Create a schema in presto:

presto> create schema minio.books;

presto> use minio.books;

Import your MySQL table into Presto:

presto:books> create table minio.books.list as select * from mysql.books.book;

This will copy the MySQL table into a Presto table.

Test

presto:books> select count(*) from list;

Benchmarks

PrestoDB is 2.5x faster than MySQL in this test.

MySQL (27.80 seconds):

presto> select count(*) from book where BINARY title like '%Red%';

PrestoDB (11 seconds):

presto> select count(*) from list where title like '%Red%';

Possible Errors

Error:

presto> create table minio.books.author as select * from mysql.books.author;

Query 20210204_070906_00000_7d4wf failed: Unsupported Hive type: varchar(16777215). Supported VARCHAR types: VARCHAR(<=65535), VARCHAR.

Solution:

This means a column in your MySQL table is either 1) a datatype that is not supported by presto or 2) exceeds the maximum character count. I changed each of the columns in MySQL to VARCHAR.

____________

Error:

2021-02-03T01:48:57.973+0900 ERROR main com.facebook.presto.server.PrestoServer No factory for connector mysql java.lang.IllegalArgumentException: No factory for connector mysql at com.google.common.base.Preconditions.checkArgument(Preconditions.java:145)

Solution:

This means you are missing the MySQL plugin located here:

Try deleting the ~/Desktop/source/presto folder and re-unpacking presto-server-0.246.tar.gz (tar xzf presto-server-0.246.tar.gz). Feel free to save the ~/Desktop/source/presto/etc folder so you don't have to re-create your configuration files.

__________

Error:

Exception in thread "main" java.lang.NoSuchMethodError: 'void com.google.common.base.Preconditions.checkArgument(boolean, java.lang.String, java.lang.Object)'

Your issue is the incompatibility between the guava version and other binary versions you are using.

$ mv $HIVE_HOME/lib/guava-19.0.jar $HIVE_HOME
/lib/guava-19.0.jar.bak

$ cp $HADOOP_HOME/share/hadoop/common/lib/guava-27.0-jre.jar $HIVE_HOME/lib/
